LPG TRANSFER PUMP

LPG transfer pumps are designed, manufactured and identified in accordance with the European Parliament directives (Equipment or Protective Systems Intended For Use In Potentially Explosive Atmospheres - 2014/34/EU).

LPG transfer pump is a self-priming side channel pump capable of handling gas along with the liquid and operates at a low noise level. LPG transfer pumps are used for problem-free pumping of clean liquids at unfavourable suction conditions.

FEATURES	TYPICAL APPLICATIONS
Quiet Operations	LPG Industry
High – Resistant Materials	Petrochemical Industry
High Efficiency	Portable Tanks
Modular Hydraulic System	Cylinder Filling Systems

Product Type	Maximum Flowrate (L/min)				Maximum Pressure (Bar)				Max. Pump Speed (rpm)	Temperature Range
Product Type	05	06	07	08	05	06	07	08	1500	-40⁰C / +80⁰C
30 yy	90	90	95	95	26	30	32	35
40 yy	125	150	175	200	26	30	32	35
50 yy	200	250	300	335	26	30	32	35
60 yy	300	350	400	500	26	30	32	35
